Cameras – 77-656# Blow 5MP BL-A5KE28BWM Analog Tube Camera

77-656# BLOW 5MP BL-A5KE28BWM Analog Tube Camera

BLOW 5MP/4K BL-A5KE28BWM Analog Camera

AHD/CVI/TVI/CVBS | 5MP/4K Lite | IP67 | TUBULAR | OUTDOOR

Image Sensor: 1/3" CMOS

Resolution: 4K: 3840×2160; 5M: 2592×1944 ; 4M: 2560×1440 ; 2M: 1920×1080

Video Output: AHD: 8M@15fps, 5M@20fps/12.5fps, 4M@30fps/25fps/15fps, 2M@30fps/25fps;

TVI: 8M@15fps/12.5fps,5M@20fps/12.5fps, 4M@30fps/25fps/15fps, 2M@30fps/25fps;

CVI: 8M@15fps/12.5fps,4M/2M@30fps/25fps

Lens: 2.8mm fixed focal length

UTC Control: Yes

OSD: Yes

Infrared range: 25 meters

FullColor: No

Audio: /

AOC function in the TVI system—available only with BLOW! recorders

Compatible models: BL-D31W / BL-D116

Housing: Front: Metal | Base: Plastic

Protection rating: IP67
