Blow

EAN:5453002615157

Converters – 77-176# Inverto Quad Black Ultra Satellite Converter

Converters – 77-176# Inverto Quad Black Ultra Satellite Converter

Laos: 1 jäänud

Quantity
Regular price €38,18 EUR
Regular price Sale price €38,18 EUR
Müük Sold out
Taxes included. Shipping calculated at checkout.
View full details

Overview

77-176# INVERTO Quad Black Ultra Satellite Converter

INVERTO QUAD BLACK ULTRA SATELLITE CONVERTER The INVERTO satellite converter is a high-quality device designed for full-range reception of satellite programs broadcast in both vertical and horizontal polarization. Manufactured to the highest industry standards and meeting all requirements, these converters are the ideal solution for satellite reception in Europe.

Key features:

Satellite TV in Full HD and 4K quality The exceptionally low noise level ensures reliable TV and radio signal reception under any conditions. The device ensures reception of virtually any channel in 4K and Full HD quality; regardless of outdoor conditions, the picture will always be smooth and free from any interference.

Up to four devices per converter It allows you to receive satellite TV from a single satellite and distribute the signal to up to 4 set-top boxes (or two dual-tuner PVRs) without the need for an external multiswitch. The LNB converter supports HD and UHD transmissions, provides excellent RF performance, has very low power consumption, and—importantly—is designed to mitigate interference from 4G/LTE transmissions.

Specifications:

Key features

High cross-polarization isolation
Maximum reliability
Capability to connect four tuners
Supports HD and 4K resolutions
Weatherproof
Higher conversion gain
Excellent signal-to-noise ratio
Compatible with all tuners and satellite TV providers available in Europe
Technical specification
SpecificationDetail
Lower band – input10.7 GHz ~ 11.7 GHz
Lower band – output950 MHz ~ 1950 MHz
Lower oscillator9.75 GHz
Upper band – input11.7–12.75 GHz
Upper band – output1,100–2,150 MHz
Upper oscillator10.6 GHz
Intrinsic noise0.2 dB (max. 0.7 dB)
Oscillator temperature drift±3 MHz max
Phase noise-90 dBc/Hz max
VSWR2.0:1
Current consumption200 mA max. @ 11 V DC – 20 V DC
Operating temperature-30° to +60°C
Weight344 g
