Converters – 77-185# Inverto Octo Premium Satellite Converter

77-185# Inverto Octo Premium Satellite Converter

This specially designed converter meets the global demand of the DTH market related to 4G and LTE. The Octo Home Pro enables reception using the latest technology—it supports HD and UHD transmissions. It delivers excellent performance with very low power consumption. It allows you to receive satellite TV from a single satellite and distribute the signal to up to 8 set-top boxes (or four PVRs with two tuners each).

Features : - Low phase noise, DVB-S2 compliant (HD and UHD) - Low noise figure- Low current consumption- High cross-polarization- High frequency stability Specifications:

- Input frequency range: 10.7 GHz ~ 12.75 GHz

- Output frequency range: 950 MHz ~ 1950 MHz

- Low LO frequency band: 9.75 GHz

- High LO frequency band: 10.6 GHz

- Noise level: 0.7 dB typ. (max. 1 dB)

- Frequency accuracy: LO @ 25 °C ± 500 kHz max.

- Temperature drift: ±800 kHz max.

- LO phase noise at 10 kHz: -90 dBc/Hz max

- Conversion gain: 55 dB min.

- Ripple gain: (bandwidth above 26 MHz) ±0.6 dB

- Gain variation (across the entire bandwidth): ±4 dB

- Image rejection: 40 dB

- Cross-polarization isolation: 22 dB min.

- VSWR: 2.3:1

- Current consumption: 210 mA max. @ 11 V DC – 20 V DC

- Operating temperature: -30° to +60°C

- Weight: 299 g
