Description
Manufacturer's number:
Steinberg Systems 10030381Chain winch The German brand Steinberg Systems is a versatile device that will be perfect for various manufacturing companies, mechanics, warehouses or construction sites. Its basic application is lifting and lowering heavy objects.
The hand-held chain lift allows you to carry objects up to 6000 kg up to five meters high. Thanks to the durable chains (type G80, 10 mm diameter cell) and the construction of high quality steel components, the operation with the SBS-FZ 6000/5M model is very safe. This is also influenced by the rubberized tip of the control bar and the lock to stop the load at the indicated height. To increase user comfort, the winch has been
with two rotating hooks and light-weight levers connected with a mechanism inside the enclosure. It allows for comfortable lifting and lowering of the object.
Product features: - - Productivity - maximum load capacity up to 6000 kg allows lifting of objects up to 5 m height,
- - Comfort - control lever and lock to stop the winch,
- - Security - steel construction, high quality of construction, two rotating hooks and a lever with anti-slip handle.
Technical parameters: - - Model - SBS-FZ 6000/5M
- - Catalog number - 10030381
- - The state of the article - New
- - Max. capacity - 6000 kg
- - Material - Steel
- - Max. lifting height - 5 m
- - Min. distance between hooks - 640 mm
- - The required force to lift the weight - 320 N
- - Chain type - G80
- - Number of carrier chains - 2
- - Wed link chain - 10 mm
- - User manual - Yes.
- - Dimensions (DxSxW) - 73 x 13 x 20.5 cm
- - Weight - 42.5 kg
- - Dimensions of dispatch (DxSxW) - 52 x 22.5 x 22 cm
- - Weight of shipping - 43.1 kg
Included: - Chain winch
- EN Instructions
