INVERTO

EAN:5453002616840

Converters – INVERTO Home Pro Twin Converter

Converters – INVERTO Home Pro Twin Converter

20 in stock

€18,74 EUR
€18,74 EUR
Sale Sold out
Taxes included. Shipping calculated at checkout.
View full details

Overview

Input frequency range: 10.7 GHz ~ 12.75 GHzOutput frequency range: 950 MHz ~ 2150 MHzLow

Technical specification
SpecificationDetail
frequency LO frequency9.75 GHzHigh
order intermodulation – ICP310 dBm min. 1 dB compression point (@ output): 0 dBm min. Polarization crosstalk: 22 dB typ. Ca control signal (V): 11.0 V ~ 14.0 V Cb control signal (H): 16.0 V ~ 20.0 V Cb control signal (H): 22 kHz – 4 kHz, 0.4 V ~ 0.8 V pp VSWR output: 2.5:1 In
band apparent power level-60 dBm max. Current consumption: max. 120 mA @ 11 VDC ~ 20 VDCT Operating temperature: -30 °C ~ +60 °COutput impedance: 75 ohmsOutput connector type: Type F (female)F/D ratio: 0.6Weight: 218 g
