Description
Manufacturer's code:
10062387Diagnostic scanner
OBD2 quickly and precisely reads the error memory in the car - just press the button. You can use standard codes to identify which system works incorrectly. If necessary, it will also delete the read codes. The set values can be read in seconds on a large display
LCDThe tester is compatible with all vehicles with interface
OBD2. Without prior knowledge, you can easily use the tool. Just connect it to the interface
OBD2 vehicle, and equipment will read the error codes. Green, yellow and red LEDs
LED signal errors. Thanks to the stop-clap function, the device remembers the established codes and status information. This includes error codes, speed, rotation, water temperature, etc.
DTC Depending on the code, it is possible to delete the entry using diagnostic scanner, e.g. after the errors have been eliminated. Tester records to
249 types of parameters and working with protocols: CAN, VPW, PWM, ISO9141, KWP2000.
in the languages of: English, German, Spanish, French, Dutch, Italian, Finnish, Russian, Portuguese, Turkish and Polish. Scanner register
information such as, inter alia,: fault codes, description and solution, vehicle identification number (VIN), software identification number of the installed control unit (ID), calibration control number (CVN), current data for the on-board computer (PCM), engine control unit status (ECU), standby code, O2 sensors waiting for DTC repair.
9 different reading modes: Rich-to-Lean O2 threshold voltage, Lean-to-Rich O2 threshold, low voltage sensor threshold for the measurement of switching time, high voltage sensor threshold for the measurement of switching time, Rich-to-Lean switching time in ms, Lean-to-Rich switching time in ms, minimum voltage for test, maximum voltage for test and time between voltage changes in ms.
Product features: - - Easy connection in all OBD2 compatible vehicles,
- - Precisely recognizes all general error codes and gives detailed error descriptions,
- - Reading vehicle information in seconds,
- - Easy operation and reading possible without prior experience,
- - Diagnostics in English, German, Spanish, French, Dutch, Italian, Finnish, Russian, Portuguese, Turkish and Polish.
Technical parameters: - - Catalog number - 10062387
- - The state of the article - New
- - Model - MSW-OBD3
- - Material - ABS, PVC, PC
- - Maximum voltage value [V] - 18
- - Display - LCD
- - Voltage range [V] - 8-18
- - Dimensions (DxSxW) - 7.5 x 2 x 14 cm
- - Weight - 0.2 kg
- - Dimensions of dispatch (DxSxW) - 11 x 17 x 5.5 cm
- - Weight of shipping - 0.26 kg
Included:
