UnitedSeats LGV64 12V Low Profile Air Suspension Seat
Compact build. Smooth air suspension. Trusted comfort for tight spaces.
The UnitedSeats LGV64 is a compact air suspension seat designed for industrial, agricultural, and off-road equipment where space is limited but performance is essential. Featuring a 12V integrated compressor, this seat delivers 60 mm of suspension travel, smooth ride control, and support for operators weighing 45 to 150 kg.
🛠️ Key Features
-
Low-Profile Air Suspension – 12V compressor with 60 mm suspension travel, ideal for compact cabins.
-
Wide Weight Range – Supports operators from 45 to 150 kg with reliable performance.
-
Flexible Slide Rails – 200 mm of fore/aft adjustment to suit most seating configurations.
-
Optional Turntable – Enhances accessibility with optional swivel base.
-
Optional Voltage – Available with 24V or 48V compressor as needed.
🔧 Technical Specifications
| Suspension Type |
Low-profile air suspension with 12V compressor |
| Suspension Travel |
60 mm |
| Weight Capacity |
45 – 150 kg |
| Slide Rail Travel |
200 mm |
| Optional Features |
Turntable, 24V or 48V compressor |
🚜 Compatibility
The LGV64 is an excellent fit for:
- Forklifts and compact loaders
- Construction machinery with limited cabin height
- Utility and municipal equipment
- Tractors (smaller MTZ and Kubota models)
- Industrial and warehouse transport vehicles
✅ Ideal For:
- Low-profile installations requiring air suspension
- Operators needing smooth ride comfort in compact machines
- Harsh environments needing durable suspension systems
🧭 Final Thoughts
The UnitedSeats LGV64 12V is a compact air suspension solution built to outperform in tight industrial spaces. Its broad weight range, smooth travel, and integrated compressor make it the smart upgrade for reliable comfort and professional-grade performance.
