UnitedSeats LGV84 12V Compact Air Suspension Seat
Compact size. Smooth comfort. Built for confined cabins and light-duty machines.
The UnitedSeats LGV84 is a low-profile air suspension seat with a 12V integrated compressor, designed to deliver ergonomic support and ride stability in tight working environments. With 100 mm of suspension travel and semi-automatic weight adjustment, this seat is ideal for forklifts, turf machinery, compact tractors, and municipal vehicles.
🛠️ Key Features
-
Integrated 12V Compressor – Compact air suspension system with 100 mm travel.
-
Semi-Automatic Weight Adjustment – Supports operators weighing 50 – 130 kg.
-
Height Adjustment – 80–140 mm range for personalized ride height.
-
Slide Rail Travel – 150 mm of fore/aft positioning to fit different cab sizes.
-
Optional Features – Turntable and 24V or 48V compressor variants available.
🔧 Technical Specifications
| Suspension Type |
Air, 12V compressor (compact) |
| Suspension Travel |
100 mm |
| Weight Adjustment |
50 – 130 kg |
| Height Adjustment |
80 – 140 mm |
| Slide Rail Travel |
150 mm |
| Options |
Turntable, 24V / 48V compressor |
🚜 Compatibility
The LGV84 seat is suitable for a wide range of light-duty and compact vehicles, including:
- Forklifts and warehouse vehicles
- Compact tractors and turf care machines
- Utility and municipal transport vehicles
- Skid-steer and mini-excavators
- ATVs, UTVs, and other small machinery
✅ Ideal For:
- Cabins with limited height or space
- Operators needing air suspension comfort in compact machines
- Light-duty construction, agricultural, and municipal vehicles
🧭 Final Thoughts
The UnitedSeats LGV84 12V offers an impressive blend of compact design and air-ride comfort—perfect for tight cabins and versatile enough for a variety of vehicles.
